112427
AmphenolUnited States

112427

ActiveCoaxial Connector (RF) Assemblies

CONN BNC RCPT STR 75 OHM SOLDER

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Connector styleBNC
GenderFemale
Impedance75 Ω
Max frequency4 GHzMax
Power
Voltage Rating500 V
AC and DC characteristics
Frequency - Max4 GHz
Impedance75Ohm
Environment and package
Mounting FeatureBulkhead - Rear Side Nut
Mounting TypePanel Mount
Operating Temperature-
PackageBag
Other
Base Product Number1124
Body FinishNickel
Body MaterialBrass
Cable Group-
Center Contact MaterialPhosphor Bronze
Center Contact PlatingGold
Connector StyleBNC
Connector TypeJack, Female Socket
Contact TerminationSolder Cup
Dielectric MaterialPolyoxymethylene (POM) Acetal
Fastening TypeBayonet Lock
FeaturesExtended Insulation
Housing ColorSilver
Includes4 pcs - 1 Connector, 1 Lockwasher, 1 Nut, 1 Solder Tag
Ingress Protection-
Insertion Loss-
Mating Cycles500
MfrAmphenol RF
Number of Ports1
Product StatusActive
Series-
Shield TerminationSolder Tag
