Honeywell Sensing and Productivity SolutionsUnited States
SWITCH SNAP ACTION SPDT 5A 250V
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 5A (AC/DC) |
| Voltage Rating - AC | 250 V |
| Voltage Rating - DC | 30 V |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -55°C~125°C |
| Package | Tray |
| Other | |
| Actuator Type | Lever, Straight |
| Base Product Number | 111SM |
| Circuit | SPDT |
| Differential Travel | 0.030" (0.76mm) |
| Electrical Life | - |
| Features | - |
| Ingress Protection | - |
| Mechanical Life | 10,000,000 Cycles |
| Mfr | Honeywell Sensing and Productivity Solutions |
| Operating Force | 198gf |
| Operating Position | 0.350" (8.9mm) |
| Overtravel | 0.030" (0.76mm) |
| Pretravel | 0.218" (5.5mm) |
| Product Status | Active |
| Release Force | 57gf |
| Series | SM |
| Switch Function | On-Mom |
| Termination Style | Solder Lug |
