WeidmüllerGermany
TERM BLOCK PLUG 15POS STR 3.81MM
All alternatives
View full reportTechnical parameters
Key specs
Positions15
Pitch3.81 mm
| Power | |
|---|---|
| Current - IEC | 17.5A |
| Current - UL | 10 A |
| Voltage - IEC | 320 V |
| Voltage - UL | 300 V |
| Environment and package | |
| Insulation Height | - |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | - |
| Package | Bulk |
| Screw Size | - |
| Other | |
| Color | Black |
| Contact Material | Copper Alloy |
| Contact Mating Finish | Tin |
| Contact Tail Length | - |
| Features | Ejector Latches, Strain Relief |
| Header Orientation | - |
| Housing Material | Polyamide (PA), Nylon, Glass Filled |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Mfr | Weidmüller |
| Number of Levels | 1 |
| Number of Positions | 15 |
| Pitch | 0.150" (3.81mm) |
| Plug Wire Entry | 180° |
| Positions Per Level | 15 |
| Product Status | Obsolete |
| Series | Omnimate BC |
| Termination Style | Screw - Clamping Yoke (Tension Sleeve) |
| Torque - Screw | 0.2-0.25 Nm (1.7-2.2 Lb-In) |
| Type | Plug, Female Sockets |
| Wire Gauge or Range - AWG | 16-28 AWG |
| Wire Gauge or Range - mm² | 0.2-1.5mm² |
| Wire Strip Length | 7mm |
