Key specs
Input voltage100 ~ 240 V
Output voltage5 V
Output current50 AMax
Power400 WMax
Outputs2
| Power | |
|---|---|
| Current - Output 1 | 50 A |
| Current - Output 2 | 5 A |
| Power (Watts) | 400W |
| Voltage - Input | 100 ~ 240 VAC |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 24 ~ 28V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -20°C ~ 70°C (With Derating) |
| Size / Dimension | 7.00" L x 4.00" W x 1.50" H (177.8mm x 101.6mm x 38.0mm) |
| Other | |
| Applications | ITE (Commercial), Medical |
| Approval Agency | CE, cURus, TUV, UKCA |
| Efficiency | 87% |
| Features | Adjustable Output, Remote Sense, Universal Input |
| Mfr | Integrated Power Designs |
| Minimum Load Required | - |
| Number of Outputs | 2 |
| Packaging | Box |
| Part Status | Active |
| Series | NXT-400 (400W) |
| Standard Number | 60601-1; 62368-1 |
| Type | Open Frame |
