Key specs
Input voltage18 ~ 36 V
Output voltage5 V
Output current30 AMax
Power150 WMax
| Power | |
|---|---|
| Current - Output (Max) | 30A |
| Power (Watts) | 150W |
| Voltage - Input (Max) | 36V |
| Voltage - Input (Min) | 18V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | 0°C ~ 70°C (With Derating) |
| Size / Dimension | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) |
| Other | |
| Applications | ITE (Commercial), Medical |
| Approval Agency | CE, cURus, TUV, UKCA |
| Efficiency | 82% |
| Manufacturer | Integrated Power Designs |
| Number of Outputs | 1 |
| Packaging | Box |
| Part Status | Active |
| Series | DC2-150 (150W) |
| Standard Number | 60601-1; 62368-1 |
| Type | Open Frame |
