Key specs
Capacitance3.3 µF
Rated voltage100 V
Tolerance20 %
Lifetime10 kh105°C
| Power | |
|---|---|
| Voltage - Rated | 100 V |
| AC and DC characteristics | |
| Ripple Current @ High Frequency | 60 mA @ 100 kHz |
| Ripple Current @ Low Frequency | 25.2 mA @ 120 Hz |
| Environment and package | |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 105°C |
| Package / Case | Radial, Can |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Surface Mount Land Size | - |
| Other | |
| Applications | General Purpose |
| Capacitance | 3.3 µF |
| ESR (Equivalent Series Resistance) | - |
| Lead Spacing | 0.079" (2.00mm) |
| Mfr | Rubycon |
| Packaging | Bulk |
| Part Status | Active |
| Polarization | Polar |
| Ratings | - |
| Series | YXM |
| Tolerance | ±20% |
