1000570021
ActiveTemp-Flex High-Performance Flat-Ribbon Cable, 20 Circuits, 0.64mm Pitch, 30 AWG, Silver Plated Copper, UL 20726, 7/38 Stranded Extruded FEP, Natural with Blue Polarity Stripe
All alternatives
View full reportTechnical parameters
| Environment and package | |
|---|---|
| Compliance: Reach Display Name | REACH SVHC |
| Compliance: Reach Status | Not Contained per D(2025)4165-DC (25 June 2025) |
| Physical: Temperature Range Operating | -55° to +150°C |
| Physical: Wire Size Awg | 30 |
| Other | |
| Compliance: Add1 Display Name | GADSL/IMDS |
| Compliance: Add1 Status | Not Relevant |
| Compliance: China Ro Hs Display Name | China RoHS |
| Compliance: China Ro Hs Status | Green Image per SJ/T 11365-2006 |
| Compliance: Elv Display Name | EU ELV |
| Compliance: Elv Status | Not Relevant |
| Compliance: Hflh Display Name | Low-Halogen Status |
| Compliance: Hflh Status | Low-Halogen per IEC 61249-2-21 |
| Compliance: Prop65 Display Name | Prop65 |
| Compliance: Prop65 Status | Not Reviewed per California Proposition 65 |
| Compliance: Ro Hs Display Name | EU RoHS |
| Compliance: Ro Hs Status | Compliant per EU 2015/863 |
| Physical: Cable Length | 100 ft/spool, 10 ft min length |
| Physical: Circuits Loaded | 20 |
| Physical: Color Cable Jacket | Natural w/Blue Polarity Stripe |
| Physical: Insulation | FEP |
| Physical: Material Outer Jacket | FEP |
| Physical: Material Plating Mating | Silver |
| Physical: Net Weight | 7.900/g |
| Physical: Packaging Type | Spool |
| Physical: Pitch Mating Interface | 0.64mm |
| Physical: Wire Cable Type | 7/38 Stranded, High-Performance Flat-Ribbon, UL 20726 |
