View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Frequency - Max | 3 GHz |
| Overall Impedance | 75 Ohms |
| Environment and package | |
| 1st Connector Mounting Feature | - |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 2nd Connector Mounting Feature | - |
| 2nd Connector Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | - |
| Other | |
| 1st Connector | BNC Plug |
| 1st Contact Gender | Male |
| 2nd Connector | HD-BNC Plug |
| 2nd Contact Gender | Male |
| Base Product Number | 095-850 |
| Cable Type | Belden 1505A |
| Color | Black |
| Features | Shielded |
| Ingress Protection | - |
| Length | 72.0" (1.8m) 6.0' |
| Manufacturer | Amphenol RF |
| Packaging | Bulk |
| Part Status | Active |
| Series | - |
| Style | BNC to HD-BNC |
