View full reportTechnical parameters
| Power | |
|---|---|
| Current - UL | 150 A |
| Voltage - UL | 600 V |
| Environment and package | |
| Panel Mount Type | 2 Piece |
| Other | |
| Color | Gray |
| Features | - |
| Front Panel Wire Connection | Bolt/Screw Clamp - Wire Entry 90° to Panel |
| Manufacturer | Phoenix Contact |
| Number of Levels | 1 |
| Packaging | Bulk |
| Panel Thickness | 0.039 ~ 0.236" (1.0 ~ 6.0mm) |
| Part Status | Obsolete |
| Pitch | - |
| Positions Per Level | 1 |
| Rear Panel Wire Connection | Screw Terminal |
| Series | CLIPLINE HDFK |
| Width | 0.740" (18.80mm) |
| Wire Gauge | 1/0-6 AWG |
Documents
No documents are linked to this part yet.
