Excelitas TechnologiesUnited States
LENS TELPHOT F4 0.066X-0.5X FLEX
All alternatives
View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Resolution | 7µm |
| TV Distortion | - |
| Environment and package | |
| Compatible Sensor Size (Max) | - |
| Filter Size | M40.5 x P0.5 |
| Mounting Type | Flexible |
| Operating Temperature | - |
| Package | Box |
| Other | |
| Depth Of Field | - |
| Diameter | 50.0mm Dia |
| Field of View | 43.3mm |
| Focal Length | 90.0mm |
| Focal Ratio | F4 |
| Length | 44.4mm |
| Magnification | 0.066x ~ 0.5x |
| Mfr | Excelitas Technologies |
| Product Status | Active |
| Series | Apo-Rodagon-N |
| Type | Telephoto |
| Weight | - |
| Working Distance | 241mm ~ 1426mm |
