Key specs
Positions4
Pitch5.08 mm
| Power | |
|---|---|
| Current - IEC | - |
| Current - UL | 15 A |
| Voltage - UL | 300 V |
| Environment and package | |
| Insulation Height | 1.010" (25.65mm) |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | 110°C |
| Screw Size | M3 |
| Other | |
| Base Product Number | 039860 |
| Color | Black |
| Contact Material | Phosphor Bronze |
| Contact Mating Finish | Tin |
| Contact Tail Length | - |
| Features | Retention Latches (Wire Side) |
| Header Orientation | - |
| Housing Material | Polyamide (PA), Nylon |
| Ingress Protection | - |
| Manufacturer | Molex |
| Material Flammability Rating | - |
| Number of Levels | 1 |
| Number of Positions | 4 |
| Packaging | Bulk |
| Part Status | Obsolete |
| Pitch | 0.200" (5.08mm) |
| Plug Wire Entry | 90° |
| Positions Per Level | 4 |
| Series | Eurostyle 39860 |
| Termination Style | Screw - Rising Cage Clamp |
| Torque - Screw | - |
| Type | Plug, Female Sockets |
| Wire Gauge or Range - AWG | 12-26 AWG |
| Wire Gauge or Range - mm² | - |
| Wire Strip Length | - |
