View full reportTechnical parameters
Key specs
Positions2
Pitch5 mm
| Power | |
|---|---|
| Current - IEC | - |
| Current - UL | 15 A |
| Voltage - UL | 300 V |
| Environment and package | |
| Insulation Height | 0.470" (11.94mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 105°C |
| Screw Size | - |
| Other | |
| Base Product Number | 039521 |
| Color | Black |
| Contact Material | Brass |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.150" (3.81mm) |
| Features | - |
| Header Orientation | Vertical |
| Housing Material | Polyamide (PA66), Nylon 6/6 |
| Ingress Protection | - |
| Manufacturer | Molex |
| Material Flammability Rating | UL94 V-0 |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Packaging | Bulk |
| Part Status | Active |
| Pitch | 0.197" (5.00mm) |
| Plug Wire Entry | - |
| Positions Per Level | 2 |
| Series | Eurostyle ESE 39521 |
| Termination Style | Solder |
| Torque - Screw | - |
| Type | Header, Male Pins, Shrouded (2 Side) |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Wire Strip Length | - |
