Key specs
Pitch3.5 mm
| Power | |
|---|---|
| Current | 12 A |
| Voltage | 300 V |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 105°C |
| Other | |
| Base Product Number | 039357 |
| Clamp Material - Plating | Copper Alloy - Nickel Plated |
| Color | Black |
| Contact Material - Plating | Copper Alloy - Tin Plated |
| Features | - |
| Housing Material | Polyamide (PA), Nylon |
| Manufacturer | Molex |
| Mating Orientation | Horizontal with Board |
| Number of Levels | 1 |
| Packaging | Bulk |
| Part Status | Active |
| Pitch | 0.138" (3.50mm) |
| Positions Per Level | 5 |
| Screw Material - Plating | Copper Alloy - Nickel Plated |
| Screw Thread | M3 |
| Series | Eurostyle 39357 |
| Torque - Screw | 0.31 Nm (2.7 Lb-In) |
| Wire Gauge | 16-28 AWG |
| Wire Termination | Screw - Rising Cage Clamp |
