View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Per Contact) | 15 A |
| Voltage - Rated | 300V |
| Environment and package | |
| Operating Temperature | 110°C |
| Other | |
| Base Product Number | 039170 |
| Control Side Cable Retainer | Jackscrew Socket |
| Control Side Connection | D-Sub, Female |
| Features | Component Area |
| Length | 2.142" (54.40mm) |
| Manufacturer | Molex |
| Packaging | Bag |
| Part Status | Obsolete |
| Positions / Poles | 15 |
| Process Side Connection | Terminal Blocks - Screw Connection |
| Series | Eurostyle 39170 |
| Width | 3.640" (92.45mm) |
| Wire Gauge | 12-26 AWG |
