View full reportTechnical parameters
Key specs
Rows2
Pitch8 mm
Current rating20 AMax
| Power | |
|---|---|
| Current Rating (Amps) | 20A |
| Voltage Rating | 300V |
| Environment and package | |
| Mounting Type | Chassis, Panel |
| Operating Temperature | 100°C |
| Other | |
| Barrier Type | Enclosed |
| Base Product Number | 039100 |
| Bottom Termination | Closed |
| Color | Clear |
| Features | - |
| Manufacturer | Molex |
| Material Flammability Rating | UL94 V-2 |
| Material - Insulation | Polyamide (PA66), Nylon 6/6 |
| Number of Circuits | 10 |
| Number of Rows | 2 |
| Number of Wire Entries | 20 |
| Packaging | Bulk |
| Part Status | Obsolete |
| Pitch | 0.315" (8.00mm) |
| Series | Eurostyle 39100 |
| Terminal Block Type | Eurostyle Terminal Strip |
| Terminal Screw Finish | Zinc |
| Terminal Screw Material | Steel |
| Top Termination | Screws |
| Wire Gauge | 12-22 AWG |
