Key specs
Rows1
Pitch9.53 mm
Current rating15 AMax
| Power | |
|---|---|
| Current Rating (Amps) | 15A |
| Voltage Rating | 300V |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 100°C |
| Other | |
| Barrier Type | 2 Wall (Dual) |
| Base Product Number | 038711 |
| Bottom Termination | Wire Wrap |
| Color | Black |
| Features | Flange |
| Manufacturer | Molex |
| Material Flammability Rating | - |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
| Number of Circuits | 6 |
| Number of Rows | 1 |
| Number of Wire Entries | 6 |
| Packaging | Bulk |
| Part Status | Discontinued at Digi-Key |
| Pitch | 0.375" (9.53mm) |
| Series | Beau 38711 |
| Terminal Block Type | Barrier Block |
| Terminal Screw Finish | Zinc, Clear Chromate |
| Terminal Screw Material | Steel |
| Top Termination | Screws |
| Wire Gauge | 14-22 AWG |
