IMS Connector SystemsGermany
All alternatives
View full reportTechnical parameters
Key specs
Impedance50 Ω
| AC and DC characteristics | |
|---|---|
| Impedance | 50 Ohm |
| Other | |
| Additional features / details | Splash-proof |
| Application | Antenna Connectors |
| Cable style | Semi rigid / Semi flexible cables |
| Cable type | RG 405, UT 85, Flexiform 405 |
| Fitting position | Rear mounting |
| Locking mechanism | Threaded Types |
| Male / Female | Female |
| Markets | Communication, Industrial |
| Packaging | Bulk packaging |
| Panel thickness max | 3 mm |
| Panel thickness min | 0 mm |
| Plating | 5 = White bronze; 9 = Ni |
| Product style | Cable mount bulkhead jack |
| Product termination | Cable connector |
| Series | TNC |
| Straight / Angle | Straight |
