View full reportTechnical parameters
| Environment and package | |
|---|---|
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 6 Stud |
| Other | |
| Base Product Number | 019098 |
| Color | - |
| Contact Finish | Electro-Tin |
| Contact Material | Copper |
| Features | - |
| Insulation | Non-Insulated |
| Insulation Diameter | - |
| Length - Overall | 0.585" (14.86mm) |
| Length - Ring Center to Termination | 0.230" (5.84mm) |
| Length - Termination | 0.179" (4.55mm) |
| Manufacturer | Molex |
| Material - Insulation | - |
| Packaging | Bulk |
| Part Status | Active |
| Series | Krimptite |
| Terminal Type | Spring, Snap |
| Termination | Crimp |
| Tongue Inside Opening | 0.114" (2.90mm) |
| Width - Outer Edges | 0.265" (6.73mm) |
| Wire Gauge | 14-16 AWG |
