View full reportTechnical parameters
| Environment and package | |
|---|---|
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 3/8 Stud |
| Other | |
| Base Product Number | 019071 |
| Color | Blue |
| Contact Finish | Electro-Tin |
| Contact Material | Copper |
| Features | Brazed Seam |
| Insulation | Insulated |
| Insulation Diameter | 0.680" (17.27mm) |
| Length - Overall | 2.620" (66.54mm) |
| Manufacturer | Molex |
| Material - Insulation | Poly-Vinyl Chloride (PVC) |
| Packaging | Bulk |
| Part Status | Active |
| Series | InsulKrimp |
| Terminal Type | Circular |
| Termination | Crimp |
| Thickness | 0.075" (1.91mm) |
| Width - Outer Edges | 0.807" (20.50mm) |
| Wire Gauge | 1/0 AWG |
Documents
No documents are linked to this part yet.
