View full reportTechnical parameters
| Environment and package | |
|---|---|
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 1/2 Stud |
| Other | |
| Base Product Number | 019071 |
| Color | Blue |
| Contact Finish | Electro-Tin |
| Contact Material | Copper Alloy |
| Features | - |
| Insulation | Insulated |
| Insulation Diameter | 0.440" (11.18mm) |
| Length - Overall | 1.876" (47.65mm) |
| Manufacturer | Molex |
| Material - Insulation | Poly-Vinyl Chloride (PVC) |
| Packaging | Bulk |
| Part Status | Obsolete |
| Series | InsulKrimp |
| Terminal Type | Circular |
| Termination | Crimp |
| Thickness | 0.057" (1.45mm) |
| Width - Outer Edges | 0.832" (21.13mm) |
| Wire Gauge | 6 AWG |
