View full reportTechnical parameters
| Base Product Number | 019035 |
| Color | Red |
| Contact Finish | Tin |
| Contact Material | Copper |
| Diameter - Barrel | 0.156" (3.96mm) |
| Features | - |
| Insulation | Non-Mating End Insulated |
| Insulation Diameter | 0.140" (3.56mm) |
| Length - Barrel | - |
| Length - Overall | 0.986" (25.04mm) |
| Manufacturer | Molex |
| Material - Insulation | Polyamide (PA), Nylon |
| Packaging | Tape & Reel (TR) Cut Tape (CT) |
| Part Status | Active |
| Series | Avikrimp |
| Terminal Type | Male, Pin (Plug) |
| Termination | Crimp |
| Wire Gauge | 18-22 AWG |
