全部替代型号
查看完整报告技术参数
| 电源 | |
|---|---|
| Current Rating (Amps) | 15A |
| Voltage Rating | 125VAC |
| 环境与封装 | |
| Mounting Type | Panel Mount, Snap-In |
| Package | Bulk |
| Panel Cutout Dimensions | Square - 24.59mm x 24.59mm |
| 其他 | |
| Approval Agency | CSA, UL |
| Base Product Number | 208979 |
| Connector Style | NEMA 5-15R |
| Connector Type | Receptacle, Female Sockets |
| Features | - |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-2 |
| Mfr | TE Connectivity AMP Connectors |
| Number of Positions | 3 |
| Panel Thickness | 0.030" ~ 0.070" (0.76mm ~ 1.78mm) |
| Product Status | Active |
| Series | - |
| Termination | IDC |
