全部替代型号
查看完整报告技术参数
| 环境与封装 | |
|---|---|
| Board Size | 9.687" L x 1.125" W x 0.062" H (246.00mm x 28.60mm x 1.57mm) |
| Mounting Hole Diameter | 0.144" (3.66mm) |
| Package | Bulk |
| 其他 | |
| Contact Finish | Tin |
| Contact Material | Brass |
| Features | Miniature Strip |
| Material - Board | XP Phenolic |
| Material Flammability Rating | - |
| Mfr | Keystone Electronics |
| Number of Positions | 50 |
| Number of Rows | 2 |
| Product Status | Obsolete |
| Row Spacing | 0.812" (20.60mm) |
| Series | - |
| Terminal Type | Turret, Dual End, Double and Single Turret |
| Type | Turret Board, Scored |
