SiTimeUnited States
MEMS OSC TCXO 81.9200MHZ LVDS
All alternatives
View full reportTechnical parameters
Key specs
Frequency81.92 MHz
Frequency stability5 ppm
Supply voltage≥ 3.3 V
Output typeLVDS
| Power | |
|---|---|
| Current - Supply (Disable) (Max) | 35mA |
| Current - Supply (Max) | 55mA |
| Voltage - Supply | 3.3V |
| AC and DC characteristics | |
| Frequency | 81.92 MHz |
| Frequency Stability | ±5ppm |
| Spread Spectrum Bandwidth | - |
| Environment and package | |
| Height - Seated (Max) | 0.039" (1.00mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -20°C~70°C |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | 6-SMD, No Lead |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) |
| Other | |
| Absolute Pull Range (APR) | - |
| Base Product Number | SIT5021 |
| Base Resonator | MEMS |
| Function | Enable/Disable |
| Mfr | SiTime |
| Output | LVDS |
| Product Status | Active |
| Ratings | - |
| Series | SiT5021 |
| Type | TCXO |
